Double wire panel 8/6/8, mesh 50 x 200 mm

Durable double wire panels made of both blank and galvanised wire and coated with a polyester powder coating. These very solid 8/6/8 double wire fences are perfectly suited for industrial estates, sports stadiums, public buildings, airfields, schools, etc. The threaded rods are welded at the intersections so that these wire panels observe high safety standards.

Four standard Ral colors
6005, 6009, 7016 en 9005. Other colours on request.

View dimensions
ø (mm)Centers (mm)Width (mm)Height (mm)
8 / 6 / 850 x 2002508630
8 / 6 / 850 x 2002508830
8 / 6 / 850 x 20025081030
8 / 6 / 850 x 20025081230
8 / 6 / 850 x 20025081430
8 / 6 / 850 x 20025081630
8 / 6 / 850 x 20025081830
8 / 6 / 850 x 20025082030
8 / 6 / 850 x 20025082230
8 / 6 / 850 x 20025082430
Specifications of wire mesh panels made of galvanised wire

The panels have been galvanised according to EN 10244-2, Class D, with a minimum zinc layer of 40 g/m². The polyester powder coating has an average thickness of 100 µm.

Specifications of wire mesh panels made of blank wire

The panels have been galvanised according to EN 1461. The polyester powder coating has an average thickness of 100 µm.
